2. Commissioning
2-21
Festo P.BE-CPX-FB32-EN en 1111a
Installing EDS files
Y o u will require the following files for the CPX terminal:
File type
Filename Language Description
EDS cpx_fb32.eds English Provides the communication adapter in the
configuration program.
ICO cpx_fb32.ico – Icon file for representing the CPX terminal or
mode in the configuration program.
Tab. 2/12: Configuration files (EDS) for CPX terminal for EtherNet/IP
Installing EDS files • Install the files with your configuration program.
Icon files Depending on the configuration program used, you can
assign icon files (.ico format) to the CPX terminal or the CPX
modules. The CPX terminal or the modules will then be
represented accordingly in the configuration program.
Instructions on installing the EDS files and the icon files can
be found in the documentation for your configuration
program.
