3. Diagnostics
3-17
Festo P.BE-CPX-FB32-EN en 1111a
Overview of diagnostic data with Explicit Messaging
The following EtherNet/IP Objects offer detailed diagnostic
information:
Object
classes
Name Diagnostic data
101
d
General Module Parameter
Object
– Faulty channel type
– Number of the faulty channel
– Module error number
133
d
Status and Diagnostic Object – Number of the module in which an e rror has
occurred
– Diagnostic status
(specifies whether there are diagnostic data).
– System error number
134
d
Diagnostic Trace Object – Long-term memory
(max. 40 entries)
– Detail diagnosis + relative time stamp per error
event
135
d
Diagnostic Trace S tatus Object – Number of entries in the diagnostic memory
– Trace status
Tab. 3/5: Diagnostic data with Explicit Messaging
