C. EtherNet/IP Objects of the CPX-FB36
C-11
Festo CPX-FB36-EN en 1611a English
Attr.
no.
Access Description Type
8 Get/Set TTL Value
for EtherNet/IP multicast packets
USINT
9 Get/Set Mcast config
IP multicast address configuration
– Alloc Control
– Reserved
– Num Mcast
– Mcast Start Addr
STRUCT of
USINT
USINT
UINT
UDINT
10 Set SelectAcd
0: Disable
1: Enable (default)
BOOL
11 Get/Set LastConflictDetected:
– ACDactivity
– RemoteMAC
– ArpPDU
STRUCT of
USINT
ARRAY of
6 USINT
ARRAY of
28 USINT
12 Set QuickConnect
0: Disable (default)
1: Enable
BOOL
Tab. C/9: Network settings with TCP/IP Interface Object -
part 2
