C.3 Objects for the I/O connection
C.3.1 “Assembly Object”
Object class: 4
d
Instances: 5
The Assembly Object bundles together attributes of various
objects, so that exchange of data with the objects can take
place over one connection.
The following instances are saved in the Assembly Object:
Instance
Description
100 Output data
101 Input data
102 Configuration data
110 Output data with padding
(Output data in the INT format)
111 Input data with padding
(Input data in the INT format)
Tab. C/11: Instances for Assembly Object
