Festo CPX-FB36 - Pneumatic Modules

D. Modbus
®
TCP objects of the CPX-FB36
D-10
Festo CPX-FB36-EN en 1611a English
D.4.3 Pneumatic modules
Modbus®
address
1)
MPA1 pneumatic module (1 … 8 valves)
Inputs process data Outputs process data
Bit 15 12 11 8 7 4 3 0 15 12 11 8 7 4 3 0
n x Echo outputs x Outputs
n+1 Module diagnostics data –
1) n corresponds to the first Modbus® address of the module.
Tab. D/13: MPA1 pneumatic module
Modbus®
address
1)
MPA2 pneumatic module (1 … 4 valves)
Inputs process data Outputs process data
Bit 15 12 11 8 7 4 3 0 15 12 11 8 7 4 3 0
n x Echo
outputs
x Outputs
n+1 Module diagnostics data –
1) n corresponds to the first Modbus® address of the module.
Tab. D/14: MPA2 pneumatic module
