C.4.2 “Global System Object” for operating mode “Remote I/O”
Object class: 132
d
Instances: 1
This Object is only available in the operating mode Remote I/O.
Attr.
no.
Access Description Type Function no.
1 Get CPX operating mode (bit 0 … 3)
0: Remote I/O without FEC/CEC
1: Remote I/O with FEC or CEC
2: Remote controller without bus node
3: Remote controller with bus node
BYTE 0 (bit 0 … 3)
CPX expansion (bit 4)
Specifies whether the current CPX expansion
corresponds to the saved CPX expansion.
0: equal
1: unequal
0 (bit 4)
Operator unit (bit 5)
Specifies whether or not an operator unit is
connected.
0: No operator unit is connected
1: Operator unit connected
0 (bit 5)
Force mode (bit 6)
Specifies whether Force is disabled or enabled.
0: disabled
1: enabled
0 (bit 6)
Bit 7: reserved 0 (bit 7)
Tab. C/22: Attributes of the System Object for operating mode RemoteI/O (part 1)
