C. EtherNet/IP Objects of the CPX-FB36
C-19
Festo CPX-FB36-EN en 1611a English
Attr.
no.
Access Description Type
5 Get Status
Bit 0: Owned
Bit 1: reserved, shall be 0
Bit 2: Configured
Bit 3: reserved, shall be 0
Bit 4-7: Extended Device Status
Bit 8: Minor Recoverable Fault
Bit 9: Minor Unrecoverable
Fault
Bit 10: Major Recoverable Fault
Bit 11: Major Unrecoverable Fault
Bit 12-15: reserved, shall be 0
WORD
6 Get Serial Number UDINT
7 Get Product name
– CPX-FB36 Remote I/O
– CPX-FB36 Remote controller
SHORT_
STRING
14 Get/Set Semaphore STRUCT
100 Get Operating Mode
– Remote Controller: TRUE
– Remote I/O: FALSE
BOOL
101 Get External Module Identifiers ARRAY
Tab. C/21: Attributes of the Identity Object - part 2
