1.2 Settings of the DIL switches
The following settings can be made through the DIL switches:
– Operating mode and network protocol
– Diagnostic mode or data field size
– IP addressing
The settings of the DIL switches become effective only after
the power supply is switched on.
1.2.1 Removing and attaching cover
To set the DIL switches at the bus node, the cover must be
removed.
Removing the DIL switch cover
1. Switch off power supply.
2. Unscrew the screws.
3. Remove the DIL switch cover.
Attaching the DIL switch cover
1. Put the DIL switch cover in place. Make sure that the seal
is seated correctly.
2. Tighten the screws. Tightening torque: max. 0.4 Nm.
