Festo CPX-FB36 - Diagnostic Memory (Groups C and E

D. Modbus
®
TCP objects of the CPX-FB36
D-21
Festo CPX-FB36-EN en 1611a English
D.5 Diagnostic memory (Groups C and E)
Modbus®
address
Diagnostic memory parameters and data
Read access
Input data
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
45648 Run/stop filter 1 (CPX function number 3480)
45652 Run/stop filter 2 (CPX function number 3484)
45652 Error end filter (CPX function number 3484)
45652 Error number filter (CPX function number 3484)
45652 Module/channel filter (CPX function number 3484)
45653 Module number MN (CPX function number 3485)
45654 Channel number CN (CPX function number 3486)
45655 Error (fault) number FN (CPX function number 3487)
45650 Diagnostic memory data – number of entries (CPX function number 3482)
45651 Diagnostic memory data – overrun (CPX function number 3483)
45651 Diagnostic memory data – status (CPX function number 3483)
45656 Diagnostic memory data (CPX function number 3488 + n
1)
)
… …
1) è CPX system description P.BE-CPX-SYS-...
Tab. D/29: Read access to diagnostic memory parameters and data
