2.3 Notes on commissioning of the CPX-FB36
Configuration of the CPX terminal requires an exact proced
ure, as different configuration specifications are sometimes
necessary for each station in the network, due to the modular
structure.
Detailed instructions and further information can be found in
the documentation or the online help for the controller or
control program.
Note
The bus node CPX-FB36 can be used on all EtherNet/IP or
Modbus® TCP controllers.
The following section describes the configuration and com
missioning procedure using the example of a controller
from Allen-Bradley with the help of the “Studio 5000” soft
ware from Rockwell Automation.
2.3.1 Requirements for commissioning
– Installation of the bus node is complete.
– The DIL switches of the bus node are set correctly.
– All connecting cables are connected and checked.
