Festo CPX-FB36 - TCP;IP Interface Object

C. EtherNet/IP Objects of the CPX-FB36
C-10
Festo CPX-FB36-EN en 1611a English
C.2.3 “TCP/IP Interface Object”
Object class: 245
d
Instances: 1
The network settings of a device are configured with the TCP/
IP Interface Object.
Attr.
no.
Access Description Type
1 Get Status (Interface Status) DWORD
2 Get Configuration Capability
Bit 5: Hardware configurable
Bit 6: Interface configuration
change requires reset
Bit 7: AcdCapable
DWORD
3 Get/Set Configuration Control DWORD
4 Get Physical Link Object
– Path Size
– Path
STRUCT of
UINT +
Padded
EPATH
5 Get/Set Interface Configuration
– IP Address
– Network Mask
– Gateway Address
– Name Server
– Name Server 2
– Domain Name
STRUCT of
UDINT
UDINT
UDINT
UDINT
UDINT
STRING
6 Get/Set HostName STRING
Tab. C/8: Network settings with TCP/IP Interface Object -
part 1
