2. Preparing for commissioning
2-8
Festo CPX-FB36-EN en 1611a English
“QuickConnect” is available for the following pneumatic mod
ules and pneumatic interfaces:
Pneumatic modules
Type
MPA1 pneumatic module VMPA1-FB-EM...-8
MPA2 pneumatic module VMPA2-FB-EM...-4
MPA1 pneumatic module with diagnostic
function
VMPA1-FB-EM...-D2-8
MPA2 pneumatic module with diagnostic
function
VMPA2-FB-EM...-D2-8
Tab. 2/2: Pneumatic modules that support “QuickConnect”
Pneumatic interfaces
Type
for VTSA or VTSAF pneumatics VABA10S6X1
for MPAS valves VMPAFBEPL…
for MPAF valves VMPAFFBEPL...
for MPAL valves VMPALFBEPL...
VMPALEPLCPX
Tab. 2/3: Pneumatic interfaces that support “QuickConnect”
2.1.3 “Device Level Ring” protocol (DLR)
The Device Level Ring protocol (DLR) allows multiple devices
to be operated in a ring topology.
Requirements
All DLR devices feature an integrated Ethernet switch with at
least 2 external ports and support the DLR Protocol.
