1. Installation
1-13
Festo CPX-FB36-EN en 1611a English
1.3.2 Overview of connection technology and network plug connectors
Note
Faulty installation and high transmission rates may cause
data transmission errors as a result of signal reflections
and attenuations.
 Observe cable specification (è Tab. 1/7).
Transmission errors can be caused by:
 faulty screened connection
 branches
 transmission over distances which are too long
 unsuitable cables.
Connection technology
Network connectors
2 x socket M12, D-coded, 4-pin, in accordance
with IEC 61076-2, SPEEDCON compatible
Plug connector NECU-M-S-D12G4-C2-ET
Tab. 1/6: Overview of connection technology and network plug connectors
RJ45 to M12 converter
For EtherNet/IP installations, it may be necessary to change
between RJ45- and M12 connection technology.
Example: Connections between devices in a control cabinet
and IP65/IP67 devices.
