D. Modbus
®
TCP objects of the CPX-FB36
D-11
Festo CPX-FB36-EN en 1611a English
Modbus®
address
1)
Pneumatic interface for CPA pneumatic set to 1 ... 8 valves
Inputs process data Outputs process data
Bit 15 12 11 8 7 4 3 0 15 12 11 8 7 4 3 0
n
x Echo outputs x Outputs
n+1 Diagnostic data –
1) n corresponds to the first Modbus® address of the module.
Tab. D/15: Pneumatic interface for CPA pneumatic (1 ... 8 valves)
Modbus®
address
1)
Pneumatic interface for CPA pneumatic set to 1 ... 16 valves
Inputs process data Outputs process data
Bit 15 12 11 8 7 4 3 0 15 12 11 8 7 4 3 0
n Echo outputs Outputs
n+1 Diagnostic data –
1) n corresponds to the first Modbus® address of the module.
Tab. D/16: Pneumatic interface for CPA pneumatic (1 ... 16 valves)
