2. Preparing for commissioning
2-13
Festo CPX-FB36-EN en 1611a English
Bus node not configured
LED indicator Status and significance
Lights up green
[MS] – Device ready for operation
Lights up green
[PS] – Power supply (Power System, PS) is OK
– Operating voltage present
(in the approved range)
Flashes green
[NS] – Network communication present but not con
figured (operating status “online”),
In this case, this is correct, because the bus
node is not configured.
Lights up green
[PL] – Load voltage present
(in the approved range)
1)
Lights up green
[TP1], [TP2] – Device is correctly connected to the bus node
– Internal communication between bus node and
device 1 or device 2 is error free
– Operating and load voltage present
(in the approved range)
1)
1) Display dependent on monitoring and signal from the connected
device.
Tab. 2/4: Status LEDs after switch-on –
bus node not configured
