Function
25
The physical properties of one or more drives on the device can be stored to support special applica-
tions with drive combinations or drives that are not included in the list (
è
4.4 Set parameters for
the description of user-defined drives). They can then be selected for use via the "Drive type" system
parameter.
Drive stroke
The drive stroke describes the maximum stroke of the drive without taking into account the mechan-
ical stops within the total stroke.
ID Value range Value digit Digit range
21
1)
10 … 5000 mm 1 mm 10 … 5000 × 1 mm
1) The "drive stroke" parameter does not need to be defined when a semi-rotary drive is selected as the drive type. The value for the
swivel angle is determined from the order code for the semi-rotary drive.
Tab. 19: Drive stroke
Volume at (2)
ID Value range Value digit Digit range
40 0 … 32 mm 0.001 l 0 … 32000 × 0.001 l
Tab. 20: Volume at (2)
Volume at (4)
ID Value range Value digit Digit range
41 0 … 32 mm 0.001 l 0 … 32000 × 0.001 l
Tab. 21: Volume at (4)
Operating medium
ID Value range Value digit Digit range
42 1 … 32767 1 1 … 32767 × 1
Tab. 22: Operating medium
Mounting position of drive
ID Value range Mounting position Value digit Digit range
60 –180° … +180°
°0°081±
+90°
–90°
0.01° –18000 … 18000 × 0.01°
Tab. 23: Mounting position of drive
