Function
27
Sensor input for end position detection, advanced
ID Value digit Value range
1)
71 1 [20 … 27] or [40 … 47] and [50 … 57] or [80 … 87] and [90 … 97]
1) dependent on valve and linkage
Tab. 27: Sensor input for end position detection, advanced
Sensor input for partial stroke measurement, retracted
ID Value digit Value range
1)2)
75 1 [20 … 27] or [40 … 47] and [50 … 57] or [80 … 87] and [90 … 97]
1) dependent on valve and linkage
2) Value = –1, if partial stroke measurement not used
Tab. 28: Sensor input for partial stroke measurement, retracted
Sensor input for partial stroke measurement, advanced
ID Value digit Value range
1)2)
76 1 [20 … 27] or [40 … 47] and [50 … 57] or [80 … 87] and [90 … 97]
1) dependent on valve and linkage
2) Value = –1, if partial stroke measurement not used
Tab. 29: Sensor input for partial stroke measurement, advanced
Sensor input for full stroke measurement
ID Value digit Value range
1)2)
80 1 [20 … 27] or [40 … 47] and [50 … 57] or [80 … 87] and [90 … 97]
1) dependent on valve and linkage
2) Value = –1, if full stroke measurement not used
Tab. 30: Sensor input for partial stroke measurement, full stroke measurement
Sensor input for flow measurement at (2)
ID Value digit Value range
1)2)
81 1 [20 … 27] or [40 … 47] and [50 … 57] or [80 … 87] and [90 … 97]
1) dependent on valve and linkage
2) Value = –1, if flow measurement is not used
Tab. 31: Sensor input for flow measurement at (2)
Sensor input for flow measurement at (4)
ID Value digit Value range
1)2)
82 1 [20 … 27] or [40 … 47] and [50 … 57] or [80 … 87] and [90 … 97]
1) dependent on valve and linkage
2) Value = –1, if flow measurement is not used
Tab. 32: Sensor input for flow measurement at (4)
