Function
3.4.3.2 Application parameters
Application parameters describe the basic conditions under which a Motion App is to be executed,
using attributes such as mass during retracting and advancing, travel time, and acceleration. Here, the
application parameters of a parameter set can be individually adapted for each Motion App (
è
3.4.3.9
Parameter sets). This means that, for example, the “mass during retracting” can be defined differently
for different Motion Apps on the same valve.
Not all Motion Apps use application parameters.
The parameters required to run a Motion App must be transferred before starting the Motion App.
Overview of application parameters
ID Application parameters
100 Retract load
1)
101 Advance load
2)
102 Mass moment of inertia, retracting
1)
103 Mass moment of inertia, advancing
2)
120 Travel time, retracting
1)
121 Travel time, advancing
2)
124 Cushioning time until "target position reached"
126 Duration of threshold exceeded for following error
141 Tolerance for "target position reached"
142 maximum velocity
144 maximum acceleration
146 maximum braking deceleration
148 maximum jerk
150 Offset of project zero point
151 Offset of software end position negative (retracted)
1)
152 Offset of software end position positive (advanced)
2)
153 Distance to target position with constant final speed in retracting direction
1)
154 Distance to target position with constant final speed in advancing direction
2)
155 Final speed in the case of contact in the retracting direction
1)
156 Final speed in the extension direction in the case of contact
2)
182 maximum pressure rise at (2)
183 maximum pressure rise at (4)
184 Medium pressure level
200 maximum leakage for "Good" status
