Function
ID Parameter Values Meaning
Input no. × 30 + 1
1)
Sensor type 1001 SMT-8M-A-PS-24V-...
2001 SDAP-MHS-M50-...
2002 SDAP-MHS-M100-...
2003 SDAP-MHS-M160-...
2901 user-defined position sensor 1
2902 user-defined position sensor 2
2903 user-defined position sensor 3
3001 SFAB-50U-...-2SA-...
3002 SFAB-200U-...-2SA-...
3003 SFAB-600U-...-2SA-...
3004 SFAB-1000U-...-2SA-...
3101 SFAH-50U-...-PNVBA-...
3102 SFAH-100U-...-PNVBA-...
3103 SFAH-200U-...-PNVBA-...
3901 user-defined flow sensor 1
3902 user-defined flow sensor 2
3903 user-defined flow sensor 3
Input no. × 30 + 2
1)
Sensor orientation
with position sen-
sors
2)
0 Output signal rising in advancing direction
1 Output signal falling in advancing direction
Sensor orientation
for flow sensors
2)
0 positive flow rate values
1 negative flow rate values
1) Examples: the sensor type for input 0 is addressed with ID 1 (0 × 30 + 1). The sensor orientation for input 4 is addressed with ID 122
(4 × 30 + 2).
2) For analogue sensors only, e.g. SDAP-...
Tab. 34: Sensor parameters
The sensor parameters are not a component of parameter sets, because they are independent of the
valves.
For user-defined sensors, the sensor signal is interpreted according to the configured properties
è
3.4.3.5 Parameters for describing user-defined position sensors,
è
3.4.3.6 Parameters for
describing user-defined flow sensors.
