A. Technical appendix
A−7
Festo P.BE−VTSA−44−EN en 0509NH
Please note
The screw connectors of the pneumatic connections cause
a reduction in the flow rate of the valves.
Standard rated flows [l/min]
(valve size 26 mm)
Valve on valve
terminal
Valve (solo)
Valve function (identifier
1)
)
1 } 2 or 1 } 4
2 } 3/5 or 4 } 3/5
1 } 2 or 1 } 4
2 } 3/5 or 4 } 3/5
2x3/2−way valves
(T32C−A / T32H−A / T32U−A / T32N−A / T32F−A /
T32W−A)
900 1250
5/2−way valves
(M52−M / M52−A / B52 / D52)
1000 1400
5/3−way mid−position valves
 closed (P53C−M)
 pressurized/exhausted (P53U−M / P53E−M)
1000
1000 (700)
2)
1400
1400 (1000)
2)
1)
Identifier of the valve in the type code
2)
Values for the mid−position are quoted in brackets
Tab.A/5: Rated flows, valve size 26 mm (ISO size 26)
