1. Summary of components
1−16
Festo P.BE−VTSA−44−EN en 0509NH
The vertical stacking components on the VTSA valve terminal
are marked by type codes. The code is marked on the side of
the component. Identification within the type code indicates
the function of the components, e.g. identification R1 in type
code VABF−S4−1R1C2−C−10, indicates that this component is a
P−pressure regulator with 10
bar input pressure. You can
identify the vertical stacking components with the aid of the
following table. In the sales documentation and in the Festo
Configurator the valves are marked with an Indent. code.
Identification in
the type code
Ident.
code
Vertical stacking components
R1−...−6 ZF Pressure regulator plate for connection 1, input pressure 6 bar
R2−...−6 ZH Pressure regulator plate for connection 2, input pressure 6 bar
R3−...−6 ZG Pressure regulator plate for connection 4, input pressure 6 bar
R4−...−6 ZI Pressure regulator plate for connections 2 and 4, input pressure
6bar
R5−...−6 ZJ Pressure regulator plate for connections 2 and 4, input pressure
6bar, reversible
R1−...−10 ZA Pressure regulator plate for connection 1, input pressure 10 bar
R2−...−10 ZC Pressure regulator plate for connection 2, input pressure 10 bar
R3−...−10 ZB Pressure regulator plate for connection 4, input pressure 10 bar
R4−...−10 ZD Pressure regulator plate for connections 2 and 4, input pressure
10 bar
R5−...−10 ZE Pressure regulator plate for connections 2 and 4, input pressure
10 bar, reversible
F1B1 X Throttle plate for restricting the exhaust in channels 3 and 5
P1A3 ZU Vertical supply plate for providing an individual operating pressure
for a valve location
L1D1 ZT Vertical pressure cut−off plate for cutting off the individual operat
ing pressure for a valve location
Tab.1/6: Identification of the vertical stacking component in the type code
