FIBOCOM SU806 Series Hardware Guide Page 13 of 91
Performance
Description
CAT14 HSDPA: Maximum downlink rate 21Mbps
LTE features
Support 3GPP R10
Support FDD/TDD CAT4
Support 1.4-20M RF bandwidth
Downlink support 2 × 2 MIMO
Maximum uplink rate 50Mbps, maximum downlink rate 150Mbps
WLAN features
Support 2.4G WLAN wireless communication, support 802.11b,
802.11g, 802.11n, the maximum rate up to 72.2Mbps
Bluetooth
BT4.2 (BR/EDR+BLE)
Satellite positioning
GPS/BeiDou
SMS
Text and PDU modes
Point-to-Point MO and MT
SMS cell broadcast
SMS storage: stored in the module by default
LCD interface
One 4 lane MIPI_DSI interface
Support maximum HD+ 60fps (1440x720)
Camera interface
Two 4 lane MIPI_CSI interface, can support three cameras;
Main camera can support 13M 30fps at maximum
Audio interface
Audio Input:
3 analog microphone inputs
Integrated internal bias
Audio output:
Class AB stereo headphone output
Class AB differential handset output
Class D differential speaker amplifier output
USB interface
USB2.0 HS interface, with data transfer rate up to 480 Mbps
Support USB OTG (external 5V power supply)
(U)SIM interface
Two (U)SIM card interfaces supporting (U)SIM card: 1.8/3V adaptive
Support dual (U)SIM dual standby single pass, support hot plug
(closed by default)
UART interface
Three UART serial interfaces
