FIBOCOM SU806 Series Hardware Guide Page 50 of 91
Module
MIPI_CSI0_CLK_P
MCAM_RST
MIPI_CSI0_CLK_N
MIPI_CSI0_LN3_P
MIPI_CSI0_LN3_N
MIPI_CSI0_LN2_P
MIPI_CSI0_LN2_N
MIPI_CSI0_LN1_P
MIPI_CSI0_LN1_N
MIPI_CSI0_LN0_P
MIPI_CSI0_LN0_N
CAM Connector
CAM_I2C_SDA0
CAM_I2C_SCL0
MCAM_PWDN
MCAM_MCLK
CLK_P
MCLK
CLK_N
DAT3_P
DAT3_N
DAT2_P
DAT1_P
DAT1_N
CAM Connector
PWD
RST
SCL
SDA
DAT2_N
DAT0_P
DAT0_N
VDD1V85
NC
NC
VDDCAMA
AVDD
AFVDD
DVDD
VCCCAMMOT
VDDCAMCORE
DOVDD
VDD1V8
1uF
10uF
1uF
EMI
EMI
EMI
EMI
EMI
100nF
100nF 10uF
Figure 3-17 Rear camera reference design
3.17.2 Front Camera
Reference design of front camera is shown as follows:
Module
MIPI_CSI1_CLK_P
SCAM_RST
MIPI_CSI1_CLK_N
MIPI_CSI1_LN0_P
MIPI_CSI1_LN0_N
MIPI_CSI1_LN1_P
MIPI_CSI1_LN1_N
CAM Connector
CAM_I2C_SDA1
CAM_I2C_SCL1
SCAM_PWDN
SCAM_MCLK
CLK_P
MCLK
CLK_N
DAT0_P
DAT0_N
DAT1_P
CAM Connector
PWD
RST
SCL
SDA
DAT1_N
VDD1V85
NC
NC
VDDCAMA
AVDD
DOVDD
DVDD
VDD1V8
VDDCAMCORE
10uF
1uF
10uF
EMI
EMI
EMI
100nF
100nF
Figure 3-18 Front camera reference design
