4 Antenna Interface
SU806 series module support 2/3/4G main antenna/diversity reception antenna, WIFI/BT antenna and
GNSS antenna.
4.1 MAIN/DRX Antenna
SU806 series module provides two 2G/3G/4G antenna interfaces. The ANT_MIAN is used to receive and
transmit RF signal, the ANT_DRX is used for diversity reception.
Table 4-1 Main/DRX pin definition
Pin Name
Pin Number
I/O
Description
Note
ANT_MAIN
87
AI/AO
2G/3G/4G main antenna
-
ANT_DRX
131
AI
Diversity reception antenna
-
4.1.1 Operating Band
Table 4-2 Module operating band of SU806-CN
Mode
Band
Tx (MHz)
Rx (MHz)
GSM
900
880-915
925-960
1800
1710-1785
1805-1880
WCDMA
Band 1
1920-1980
2110-2170
Band 8
880-915
925-960
LTE FDD
Band 1
1920-1980
2110-2170
Band 3
1710-1785
1805-1880
Band 5
824-849
869-894
Band 8
880-915
925-960
LTE TDD
Band 34
2010-2025
2010-2025
Band 38
2570-2620
2570-2620
Band 39
1880-1920
1880-1920
