Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM SU806 Series Hardware Guide Page 42 of 91
For rear/front camera by default
For rear/front camera by default
For depth camera by default
For depth camera by default
Note:
When I2C has more than one peripheral, please ensure the uniqueness of every peripheral address.
3.10 RBG
SU806 series module provides three RGB LED inputs, its pin definition is shown in the following table:
Table 3-14 RGB pin definition
3.11 ADC
SU806 series module provides one ADC interface and its maximum resolution is 12 bits. It provides one
ADC4_BAT_ID which is use for charging temperature detection. Its pin definition is shown in the following
table:
Table 3-15 ADC pin definition
Detection voltage range is 0.1V~1.2V with
maximum 50mV accuracy and 0.1V~3.0V with
maximum 150mV test accuracy, software
configurable
