3.18 Sensor
SU806 series module supports I2C interface to communicate with various types of sensors, such as
accelerometer sensor, ambient light sensor and magnetic sensor etc.
Table 3-24 Sensor interface pin definition
Pin Name
Pin
Number
I/O
Description
Note
SENSOR_I2C_SCL
91
DO
I2C clock
-
SENSOR_I2C_SDA
92
I/O
I2C data
-
ALPS_INT_N
107
DI
Ambient light and proximity sensor interrupt
-
MAG_RST
109
DO
Magnetic sensor reset
-
ACCL_INT
110
DI
Accelerometer sensor interrupt
-
3.19 Audio
3.19.1 Audio Interface Pin Definition
SU806 series module supports analog audio, have 3 input and 3 output. Pin definition is shown in the
following table:
Table 3-25 Audio interface pin definition
Pin Name
Pin
Number
I/O
Description
Note
SPK_P
10
AO
Speaker amp+ output
Power consumption
800mW in 8Ω load
SPK_M
11
AO
Speaker amp- output
EAR_P
8
AO
Earpiece output+
Power consumption
25mW in 32Ω load
EAR_M
9
AO
Earpiece output-
HPH_L
138
AO
Headset left channel output
-
HPH_GND
137
AI
Headset ground sensing
-
HPH_R
136
AO
Headset right channel output
-
HPH_DET
139
AI
Headset detection
-
