FIBOCOM SU806 Series Hardware Guide Page 79 of 91
Mode
Band
Max Power (dBm)
Min Power (dBm)
Band 5
24+1/-3
< -49
Band 8
24+1/-3
< -49
LTE FDD
Band 1
23.0±2
< -39
Band 3
23.0±2
< -39
Band 5
23.0±2
< -39
Band 7
23.0±2
< -39
Band 8
23.0±2
< -39
Band 20
23.0±2
< -39
Band 28
23.0±2
< -39
LTE TDD
Band 38
23.0±2
< -39
Band 40
23.0±2
< -39
Band 41
23.0±2
< -39
8.5 RF Receiver Sensitivity
The sensitivity of each frequency band of the SU806 series module is shown in the following table:
Test condition:3.8V power supply, environment temperature 25°C . The test bandwidth of LTE sensitivity LTE is
10M, RB configuration please refer to 3GPP standard.
Table 8-9 RF receiver sensitivity of SU806-CN-00
Mode
Band
Primary
Diversity
PRX+Div
3GPP
Requirement
Unit
GSM
900
TBD
-
-
-102
dBm
1800
TBD
-
-
-102
dBm
WCDMA
Band 1
TBD
-
-
-106.7
dBm
Band 8
TBD
-
-
-103.7
dBm
LTE FDD
Band 1
TBD
TBD
TBD
-96.3
dBm
Band 3
TBD
TBD
TBD
-93.3
dBm
Band 5
TBD
TBD
TBD
-94.3
dBm
Band 8
TBD
TBD
TBD
-93.3
dBm
