Fibocom SU806 Series User Manual

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM SU806 Series Hardware Guide Page 41 of 91
Pin Name
Pin Number
H/L/Hiz After Reset
After Reset
Interrupt
Function
GPIO_24
207
L
INPUT(WPD)
YES
GPIO_11
241
L
INPUT(WPD)
YES
GPIO_7
242
L
INPUT(WPD)
YES
GPIO_143
243
H
INPUT(WPU)
YES
GPIO_10
244
L
INPUT(WPD)
YES
GPIO_141
97
H
INPUT(WPU)
YES
GPIO_26
252
L
INPUT(WPD)
YES
GPIO_22
253
L
INPUT(WPD)
YES
GPIO_23
254
L
INPUT(WPD)
YES
Note：
H: High-voltage tolerant
L: Low-voltage tolerant
Hiz: High impedance
WPU: Weak pull up
WPD: Weak pull down
3.9 I
2
C
SU806 series module provides four I2C interfaces for TP, camera, sensor, etc. And four I2C interfaces are
all internal pull up, when in use, please reserve pull-up resistors to 1.8V power domain. The pin definition
is shown in the following table:
Table 3-13 I2C pin definition
Pin Name
Pin
Number
I/O
Description
Note
SENSOR_I2C_SCL
91
DO
I2C clock
For sensor by default
SENSOR_I2C_SDA
92
I/O
I2C data
For sensor by default
TP_I2C_SCL
47
DO
I2C clock
For touch panel by default
TP_I2C_SDA
48
I/O
I2C data
For touch panel by default
