Fibocom SU806 Series User Manual

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM SU806 Series Hardware Guide Page 12 of 91
2.2 Product Specification
SU806 series module is available in 262 LCC+LGA package that includes 146 LCC pins and 116 LGA
pins. The dimension is 40.5mm×40.5mm×2.8mm. It can be embedded in various M2M applications. It is
suitable for the development of smart devices such as smart POS, cash registers, robots, UAVs, smart
homes, security monitoring and multimedia terminals. Its detailed performance is shown in the following
table.
Table 2-3 Main performance
Performance
Description
Power Supply
DC:3.5~4.2V, typical:3.8V
Application processor
Quad-core ARM
®
Cortex
TM
A53 MP processor, up to 1.4GHz
Memory
8GB e.MMC+8Gb LPDDR3
16GB e.MMC+16Gb LPDDR3
Power class
Class 4 (33dBm±2dB) for GSM850/EGSM900
Class 1 (30dBm±2dB) for DCS1800/PCS1900
Class E2 (27dBm±3dB) for GSM850/EGSM900 8-PSK
Class E2 (26dBm±3dB) for DCS1800/PCS1900 8-PSK
Class 3 (24dBm+1/-3dB) for WCDMA bands
Class 3 (23dBm±2dB) for LTE FDD bands
Class 3 (23dBm±2dB) for LTE TDD bands
GSM/GPRS/EDGE features
R99:
CSD transmission rate:9.6kbps,14.4kbps
GPRS:
Support GPRS multi-slot class 12
Coding formats:CS-1/CS-2/CS-3 and CS-4
4 Rx time slots per frame maximum
EDGE:
Support EDGE multi-slot class 12
Support GMSK and 8-PSK
Uplink encoding formats: CS 1-4 and MCS 1-9
Uplink encoding formats: CS 1-4 and MCS 1-9
WCDMA features
Support 3GPP R9
Support 16-QAM, 64-QAM and QPSK modulation
CAT7 HSUPA: Maximum uplink rate 11Mbps

Fibocom SU806 Series Specifications

General

Brand	Fibocom
Model	SU806 Series
Category	Computer Hardware
Language	English
