Fibocom SU806 Series User Manual

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM SU806 Series Hardware Guide Page 68 of 91
Frequency
Mode
Date Rate
Bandwidth (MHz)
Sensitivity (dBm)
802.11n
MCS0
20
-85
MCS7
20
-70
6.3 Bluetooth Overview
SU806 series module supports BT4.2 (BR/EDR+BLE) standards. The modulation method supports GFSK,
8-DPSK and π/4-DQPSK.BR/EDR. Channel bandwidth is 1MHz and can accommodate 79 channels. The
BLE channel bandwidth is 2MHz and can accommodate 40 channels. Its main features are as follows:
 BT 4.2 + BR/EDR + BLE
 Support for ANT protocol
 Support for BT-WLAN coexistence operation, including optional concurrent receive
 Up to 3.5 piconets (master, slave and page scanning)
Table 6-3 BT rate and version information
Version
Date Rate
Throughput
Note
BT1.2
1Mbit/s
> 80Kbit/s
-
BT2.0+EDR
3Mbit/s
> 80Kbit/s
-
BT3.0+HS
24Mbit/s
Refer 3.0+HS
-
BT4.2 LE
24Mbit/s
Refer 4.2 LE
-
6.4 Bluetooth Performance
Table 6-4 BT performance index
Type
DH-5
2-DH5
3-DH5
BLE
Unit
Transmitter
8±2
7.5±2
7.5±2
2±2.5
dBm
Sensitivity
-86
-88
-82
-90
dBm
Note:
The sensitivity here is a typical value.
