Fibocom SU806 Series User Manual

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM SU806 Series Hardware Guide Page 70 of 91
8 Electrical, Reliability and RF Performance
8.1 Recommended Parameters
Table 8-1 Recommended parameters
Parameter
Min
Normal
Max
Unit
VBAT
3.5
3.8
4.2
V
USB_VBUS
4.75
5
5.25
V
VRTC
-
3.0
3.35
V
Operating Temperature
-20
25
65
℃
Storage Temperature
-40
25
95
℃
8.2 Absolute Maximum Ratings
The functionality of SU806 series module is subject to the absolute maximum/minimum values listed in
the following table. Do not exceed these parameters or the part may be damaged permanently. Operation
at absolute maximum ratings is not guaranteed.
Table 8-2 Absolute maximum ratings
Parameter
Description
Min
Max
Unit
VBAT
Power supply
-0.3
5
V
USB_VBUS
VBUS 5V input
-0.3
17
V
8.3 Power Consumption
Test condition:3.8V power supply, environment temperature 25°C
Table 8-3 SU806-CN-00 Power consumption
Parameter
Description
Condition
Typical
Result
Unit
I
off
Static leakage current
Power supply, not power on
TBD
uA
