FIBOCOM SU806 Series Hardware Guide Page 52 of 91
11) The analog voltage VDDCAMA routing should be away from interference sources, otherwise it is
easy to bring interference of power noise;
12) Camera analog power supply suggest to add LDO with high PSRR ability and place it near
camera.
Table 3-23 Length of MIPI_CSI differential signal in module
Pin Name
Pin
Number
Length (mm)
Length Difference (DP-DM) mm
MIPI_CSI0_CLK_P
229
24.6976
0.2409
MIPI_CSI0_CLK_N
230
24.4567
MIPI_CSI0_LN0_P
155
24.59549
0.09393
MIPI_CSI0_LN0_N
231
24.50157
MIPI_CSI0_LN1_P
156
24.65386
0.021
MIPI_CSI0_LN1_N
232
24.63286
MIPI_CSI0_LN2_P
157
23.86664
0.13116
MIPI_CSI0_LN2_N
233
23.73548
MIPI_CSI0_LN3_P
158
23.60038
-0.04674
MIPI_CSI0_LN3_N
234
23.64712
MIPI_CSI1_CLK_P
64
10.74214
0.04892
MIPI_CSI1_CLK_N
63
10.69322
MIPI_CSI1_LN0_P
66
11.22924
-0.10242
MIPI_CSI1_LN0_N
65
11.33166
MIPI_CSI1_LN1_P
68
11.73285
0.28125
MIPI_CSI1_LN1_N
67
11.4516
MIPI_CSI1_LN2_P
73
19.19065
-0.18467
MIPI_CSI1_LN2_N
72
19.37532
MIPI_CSI1_LN3_P
71
19.95271
0.07975
MIPI_CSI1_LN3_N
70
19.87296
