Pin Name
Pin
Number
I/O
Functional Description
Note
SPI_MISO
118
DI
SPI master input slave output
-
SPI_MOSI
119
DO
SPI master output slave input
-
LCD interface
MIPI_DSI0_CLK_N
52
AO
MIPI display serial interface
clock
-
MIPI_DSI0_CLK_P
53
AO
-
MIPI_DSI0_LN0_N
54
AO
MIPI display serial interface
lane
-
MIPI_DSI0_ LN0_P
55
AO
-
MIPI_DSI0_ LN1_N
56
AO
-
MIPI_DSI0_ LN1_P
57
AO
-
MIPI_DSI0_LN2_N
58
AO
-
MIPI_DSI0_LN2_P
59
AO
-
MIPI_DSI0_LN3_N
60
AO
-
MIPI_DSI0_LN3_P
61
AO
-
LCD_RST
49
DO
LCD reset signal
-
PWM
29
DO
LCD backlight PWM
-
LCD_TE
50
DI
LCD tearing effect
Keep floating if unused
GPIO_25
190
DO
LCD backlight enable
-
Touch panel interface
TP_INT
30
DI
LCD TP interrupt signal
-
TP_RST
31
DO
LCD TP reset signal
-
Camera interface
MIPI_CSI0_CLK_P
229
AI
MIPI rear camera serial
interface clock
-
MIPI_CSI0_CLK_N
230
AI
MIPI_CSI0_LN0_P
155
AI
MIPI rear camera serial
interface lane
-
MIPI_CSI0_LN0_N
231
AI
