Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved.
FIBOCOM SU806 Series Hardware Guide Page 48 of 91
Camera focus motor drive AFVDD power
supply, 2.8V
MIPI rear camera serial interface clock+
MIPI rear camera serial interface clock+
MIPI rear camera serial interface lane 0+
MIPI rear camera serial interface lane 0-
MIPI rear camera serial interface lane 1+
MIPI rear camera serial interface lane 1-
MIPI rear camera serial interface lane 2+
MIPI rear camera serial interface lane 2-
MIPI rear camera serial interface lane3+
MIPI rear camera serial interface lane 3-
MIPI front camera serial interface clock +
MIPI front camera serial interface lane 0 -
MIPI front camera serial interface lane 0 +
