Parameter
Description
Condition
Typical
Result
Unit
I
LTE-RMS
FDD data
RMS Current
Band1@ max power(10MHz,1RB)
TBD
mA
Band3@ max power(10MHz,1RB)
TBD
Band5@ max power(10MHz,1RB)
TBD
Band8@ max power(10MHz,1RB)
TBD
TDD data
RMS Current
Band34@ max power(10MHz,1RB)
TBD
Band38@ max power(10MHz,1RB)
TBD
Band39@ max power(10MHz,1RB)
TBD
Band40@ max power(10MHz,1RB)
TBD
Band41@ max power(10MHz,1RB)
TBD
Table 8-4 SU806-CN-01/SU806-CN-11 power consumption
Parameter
Description
Condition
Typical
Result
Unit
I
off
Static leakage current
Power supply, not power on
120
uA
Software power off current
By AT command or select the power off
menu in LCM selection box
230
I
sleep
GSM
MFRMS=5
3.2
mA
WCDMA
DRX=8
3.2
TDD LTE
DPC (Default Paging Cycle)=#256
3.1
FDD LTE
DPC (Default Paging Cycle)=#256
3.1
Radio Off
AT+CFUN=4 Flight Mode
2.7
I
GSM-RMS
GSM voice
RMS Current
EGSM900@ PCL=5
256
mA
EGSM900@ PCL=19
90
DCS1800@ PCL=0
196
DCS1800@ PCL=15
89
I
GSM-MAX
GSM voice
EGSM900@ PCL=5
2200
mA
