FIBOCOM SU806 Series Hardware Guide Page 74 of 91
Parameter
Description
Condition
Typical
Result
Unit
I
sleep
GSM
MFRMS=5
3.1
mA
WCDMA
DRX=8
3.15
TDD LTE
DPC (Default Paging Cycle)=#256
2.8
FDD LTE
DPC (Default Paging Cycle)=#256
2.8
Radio Off
AT+CFUN=4 Flight Mode
2.5
I
GSM-RMS
GSM voice
RMS Current
EGSM900@ PCL=5
256
mA
EGSM900@ PCL=19
90
DCS1800@ PCL=0
196
DCS1800@ PCL=15
89
I
GSM-MAX
GSM voice
Peak current
EGSM900@ PCL=5
2100
mA
DCS1800@ PCL=0
1300
I
GPRS-RMS
GPRS data
RMS Current
EGSM900@ Gamma=3 (1UL/4DL)
240
mA
EGSM900@ Gamma=3 (4UL/1DL)
522
DCS1800@ Gamma=3 (1UL/4DL)
179
DCS1800@ Gamma=3 (4UL/1DL)
339
I
EGPRS-RMS
EGPRS data
RMS Current
EGSM900@ Gamma=6 (1UL/4DL)
169
mA
EGSM900@ Gamma=6 (4UL/1DL)
498
DCS1800@ Gamma=5 (1UL/4DL)
161
DCS1800@ Gamma=5 (4UL/1DL)
468
I
WCDMA-RMS
WCDMA
RMS Current
Band1@ max power
589
mA
Band8@ max power
598
I
LTE-RMS
FDD data
Band1@ max power (10MHz,1RB)
595
mA
