COMPONENTS 29
Not included in the motherboard kit
• USB 2.0 flash drive (32MB) with write-protection turned off.
– Not all USB 2.0 flash drives are validated for use with the E100. If a flash drive does
not work, try another brand.
•Any PC with:
– Windows Vista (32- or 64-bit) or Windows XP with Service Pack 2 or later
– CD or DVD drive
– Support for USB 2.0
– 256MB of available memory
Motherboard jumpers
The following table describes the jumper pin locations on the motherboard. Do not move or
change any of the default jumper configurations.
TABLE 1: Jumper pins on the motherboard
Location on motherboard Default jumper configuration
JP7
(on edge of motherboard, near J18)
No jumper installed
J17
(on corner of motherboard, near SATA 1
connector)
No jumper is installed
J18
(on edge of motherboard, near the on-board
speaker)
Jumper is installed on pins 1 and 2
(pin 1 is indicated by a silkscreened triangle)
J22
(on connector edge of motherboard, near the
mounting screw standoff)
No jumper is installed
J23
(on corner of motherboard, near J5)
No jumper is installed
