3. Connect the power button cables to the correct pins on J14
• SW LED cable—pins 2 and 4
• SW cable—pins 6 and 8
4. Reassemble the E100 and verify its functionality (see page 18).
1
2
17
18
SWSW LED
J14 on the motherboard
NOTE: Four wires left to right: red, black, red, yellow.
