FireClass FC503 - Default System Parameters; Default Zone Assignment

69
Table 64: Terminals description
TERM.
Description
v(V)
i(A)
Main boards
+L1- LEFT
(+)Loop 1-Positive signal, left side.
(-)Loop 1-Negative signal (return), left side
—
—
+L1- RIGHT
(+)Loop 1-Positive signal, right side.
(-)Loop 1-Negative signal (return), right side
—
—
+L2- LEFT
(+)Loop 2-Positive signal, left side.
(-)Loop 2-Negative signal (return), left side.
—
—
+L2- RIGHT
(+)Loop 2-Positive signal, right side.
(-)Loop 2-Negative signal (return), right side.
—
—
+L3- LEFT
(+)Loop 3-Positive signal, left side.
(-)Loop 3-Negative signal (return), left side.
—
—
+L3- RIGHT
(+)Loop 3-Positive signal, right side.
(-)Loop 3-Negative signal (return), right side.
—
—
+L4- LEFT
(+)Loop 4-Positive signal, left side.
(-)Loop 4-Negative signal (return), left side
—
—
+L4- RIGHT
(+)Loop 4-Positive signal, right side.
(-)Loop 4-Negative signal (return), right side
—
—
+L5- LEFT
(+)Loop 5-Positive signal, left side.
(-)Loop 5-Negative signal (return), left side
—
—
+L5- RIGHT
(+)Loop 5-Positive signal, right side.
(-)Loop 5-Negative signal (return), right side
—
—
+L6- LEFT
(+)Loop 6-Positive signal, left side.
(-)Loop 6-Negative signal (return), left side
—
—
+L6- RIGHT
(+)Loop 6-Positive signal, right side.
(-)Loop 6-Negative signal (return), right side
—
—
SH
Terminal for connection of the shield of cables
—
—
+RS485-
SERIAL BUS. Terminals to connect the FC500 and FC500MFI modules
—
—
[M]
[24R]
24 V RESET ABLE AUXILIARY POWER SUPPLY:
Negative present on terminal [M]; Positive present on terminal [24R].
27.6
0.5(1)
[M]
[24A]
24 V AUXILIARY POWER SUPPLY:
Negative present on terminal [M]; Positive present on terminal [24A].
27.6
0.5(1)
[LE]
[LI] [ - ]
Terminal for connection of the external telephone line Terminal for connection of the
internal telephone line Terminal for connection of the Earth cable
—
—
[NC]
[NO]
[C] FIRE
FIRE ALARM OUTPUT - Non-Supervised:
standby [C] connected to [NC] with [NO] open;
in the event of ALARM [C] connected to [NO] with [NC] open
—
—
[NC]
[NO]
[C] FAULT
FAULT ALARM OUTPUT - Non-Supervised:
standby [C] connected to [NC] with [NO] open
in the event of fault [C] connected to [NO] with [NC] open
—
—
+BAT-
BATTERY CONTROL PANEL POWER SUPPLY
27.6
—
[OC1] [OC2]
Programmable Outputs(Open collector)- Silenceable-Bypassable
(Disabled)-Supervised
(The polarity is not programmable)
27.6
—
[SC1]
[SC2]
(Programmable, SC2 only),Supervised, Silenceable, Bypassable (Disabled) ALARM Outputs:
Panel in Standby negative on [+] terminal; positive 27.6 V on [–] terminal
Panel in Alarm positive 27.6 V on [+] terminal; negative 0 V on [–] terminal
—
(2)
