The first flash of the beacon is synchronised with the start
of the tone. The FC410LPBS devices have a built in two
port isolator.
FC430LPSB and FC430LPASB loop powered
addressable sounder beacon base
The FC430LP series of loop powered addressable
sounder and sounder- beacons are designed to be driven
from an FC503 or FC506 control panel through the
addressable loop. Tone, volume, and flash rates are set
in the FireClass FC500 (FC501_FC503_FC506) Console.
The sounder has four volume settings High (90 dB ±3),
Mid High (80 ± 3dB), Mid Low (70 ± 3 dB) or Low (60 dB
± 3). The beacon has two flash rates Slow Flash (1/2 Hz)
or Fast Flash (1 Hz). The FC430LP Series have a built-in
line isolator.
FC430LPBSB Loop powered addressable
sounder/beacon base (EN54-23)
The FC430LPBS series of loop powered addressable
sounder and sounder- beacons are designed to be
driven from an FC503 or FC506 control panel from the
addressable loop. Tone, volume, and flash rates are set
in the FireClass FC500 (FC501_FC503_FC506)
Console.
The sounder has four volume settings High (90dB ±3),
Mid High (80 ±3dB), Mid Low (70 ±3dB), or Low (60 dB
±3). The beacon has two flash rates Slow Flash
(1/2 Hz) or Fast Flash (1 Hz). The FC430LPBS Series
have a built-in line isolator.
Table 61: EN54-2
FireClass product
code (Current Dev.)
FireClass device
name (Current Dev.)
Description
FireClass
product code
(EN54-23
Dev.)
FireClass
device name
(EN54-23
Dev.)
516.800.758
FC430LPASB
Loop powered beacon
sounder base
516.800.973
FC430LPBSB
516.800.763
FC410LPAVR
Loop powered beacon
sounder (indoor use) red
516.800.970
FC410LPBS-R
516.800.764
FC410LPAVW
Loop powered beacon
sounder (indoor use) white
516.800.971
FC410LPBS-W
516.800.766
FC410LPAV
Loop powered beacon
sounder IP65 (outdoor
use)
516.800.972
FC410LPBS
Note: It is possible to substitute old devices with the correspondent new ones (EN54-23) and to keep the same program
data. When the old device is physically removed from the loop, the control panel will signal the No answer fault. When the
new device with the same address is connected to the loop, the control panel will restore the No answer fault and
automatically update its internal database with the new device type.
It is not possible to substitute new EN54-23 devices with old devices that are not EN54-23 approved.
FC410SNM Sounder notification module
The FC410SNM Sounder notification module provides an
output, in response to a command signaled from a
controller, to activate a number of polarized and
suppressed sounders. The sounders are powered from
an independent power supply and the module is capable
of passing up to a maximum current of 2 A. For example,
24 VDC 50 mA company sounders or a mixture of
different current rated sounders not exceeding a
maximum current of 2 A.
The possibility of the configuration of extinction, although
present in the FC410SNM module, is not available for
FC503 and FC506 control panel.
Note: The extinction configuration is not available in the
FC503 or FC506 modules.
FC410TSM Door control module
The FC410TSM door control module closes a fire door
in case of alarm or fault. The door is normally kept open
by electromagnets. The door control module
disconnects the electromagnets from power supply in
order to allow the door to close. The FC410TSM has a
relay changeover output and a monitored input. The
FC410TSM contains an integrated line isolator and self-
monitoring circuits (monitoring of communication with a
panel, loop power monitoring), which enables the fire
door to be closed when communication with a panel is
lost for longer than 45 s (±5 s) or the loop power drops
below Umin=19 V for more than 15 s (± 5 s). In
addition, the FC410TSM monitors the external 24 V
supply.
