Fisher & Paykel DD60DCHB7 Service Manual

52
8 SERVICING PROCEDURES
8.3 Removal of the UI Display
https://vimeopro.com/fisherpaykeltechnical/training-videos/
video/173779838
Fig 4
Fig 3
Fig 2
Fig 1
Fig 5
1 Remove the insulation foam from the inner door.
(Fig 1)
2 Remove the aluminium brace by sliding one side
down to remove it. (Fig 2)
3 To remove the user interface display module, remove
the wedge by pulling downwards to release the
locks. (Fig 3)
4 Lift the display slightly to remove from the door and
slide out. (Fig 4 & 5)
