Fisher & Paykel DD60DCHB7 Service Manual

53
8 SERVICING PROCEDURES
Fig 1
Fig 4
Fig 2
1 Remove the drawer front, refer section 8.1.
2 To remove the stainless steel top cap, remove the
4 clips from the studs along the top of the door.
(Fig 1 & 2)
3 The top cap is also held in place with tape, so may
require a sharp knife to cut the tape as you life the
cap off the door. Shown in figure 3.
4 To remove the plastic top cap on some models, use a
pair of long nose pliers, squeeze the pins together to
release. (Fig 9)
8.4 Removal of the Top Cap
Fig 3
