67
8 SERVICING PROCEDURES
8.25 Replacing the Yoke
1 Remove the lid, refer section 8.24
2 Release the lid actuator from the bottom of the
yoke by pushing with your thumb against one of
the locking tabs.
3 Slide the front of the yoke downwards at an angle
until it moves out of the track in the rear of the
trim, and is clear of the chassis flange as shown.
4 Refit in reverse manner taking care that the yoke
is the correct way round.
NOTE: There are both left hand and right hand
yokes.
5 Do not bend the yoke when refitting it. Locate
the rear end below the chassis tab at the rear of
the chassis first, then slide the front up in behind
the trim to ensure the front yoke peg locates
correctly in the track behind it.
correctly located
incorrectly located
chassis trim
yoke
trim channel
