20
2 SPECIFICATIONS
COMPONENT SPECIFICATION
Controller AA/GB/EU/DK/PF/SG 240V
US/TW 120V
Water inlet valve 24v DC
65 +- 10 Ohms per coil
4L per minute
2.5L per minute
Dispenser coil 24V DC
65 +- 10 Ohms
Rinse aid tanks AA/GB/EU/DK/PF/SG 50 mls (approx 25 washes)
US/TW 3.05 cubic inches
Motor
Drain speed
Wash speed
80V DC 3 phase brushless
5000rpm
2200 - 2800rpm
Stator 8 Ohms per winding
16 Ohms phase to phase
Heater AA/GB/EU/DK/PF/SG 230V - 920W
55 - 60
Ohm
US/TW 120V -570W
24-27 Ohm
Thermal cut out temp 120 Deg C +- 6.5 Deg C
248 Deg F +- 42 Deg F
Temperature sensor
12000 Ω @ 20
o
C (68
o
F)
8300 Ω @ 30
o
C (86
o
F)
3000 Ω @ 60
o
C (140
o
F)
Water inlet hose Pressure rating
Length from chassis edge
(view from front)
1MPa (145psi) max
1650mm (64 3/4’’) LH side
1250mm (49’’) RH side
Water pressure Incoming water
pressure ratings
1MPa (145psi) max
0.03 MPa (4.3psi) min
Drain hose 2000mm (78 1/2’’) from LH side
1800mm (70 1/2’’) from RH side
Power cord AA/GB/EU/DK/PF/SG 1650mm
US/TW 29 1/2’’
Drying fan 24V brushless DC motor
0.27A
Lid actuator 24V DC
2.5 Component Specifications
MARKET VOLTAGE V FREQUENCY HZ CURRENT A
AA GB EU DK PF SG 220/240 50 10
US TW 120 60 10
2.4 Electrical Specifications
