Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—Transducer Block
July 2013
99
Table 4‐14. Transducer Block Parameter Definitions (Continued)
Description
Protect
Category
Initial ValueRangeMode
RO /
RW
Index
Number
Label
PARAMETER_NAME
Maintenance Suppress
MAINT_MASK
66 RW ALL
Same as for
MAINT_ACTIVE above
All bits: 0 ALL
Data Type: Bit String (4 byte)
0=disable
1=enable
Maintenance alert mask. MASK
controls whether an alert is
reported. If alert is enabled the alert
condition is evaluated and the
ACTIVE parameter is updated to
reflect if alert is active or not. If the
bit is set reporting is suppressed.
Default is all bits cleared.
Advise Suppress
ADVISE_MASK
67 RW ALL
Same as for
ADVISE_ENABLE above
All bits: 0 ALL
Data Type: Bit String (4 byte)
0=disable
1=enable
Advise alert mask. MASK controls
whether an alert is reported. If alert
is enabled the alert condition is
evaluated and the ACTIVE
parameter is updated to reflect if
alert is active or not. If the bit is set
reporting is suppressed. Default is all
bits cleared.
Failed Priority
FAILED_PRI
68 RW ALL 0 to 15 2 SETUP
Data Type: Uint8
Failed alert priority
Maintenance Priority
MAINT_PRI
69 RW ALL 0 to 15 2 SETUP
Data Type: Uint8
Maintenance alert priority
Advise Priority
ADVISE_PRI
70 RW ALL 0 to 15 2 SETUP
Data Type: Uint8
Advise alert priority
Recommended Action
RECOMMENDED_ACTION
71 RO N/A 0 to 65535 0 N/A
Data Type: Uint16
Fix for most serious condition
Travel Accumulator
TRAVEL_ACCUM
72 RW ALL
Write: Anything
Read: Actual
CAL
Data Type: Uint32
Total travel expressed in integer %
terms. Controls AI channel 13.
Cycle Count
CYCLE_COUNT
73 RW ALL
Write: Anything
Read: Actual
CAL
Data Type: Uint32
Number of cycle transitions above a
certain threshold of movement.
Controls AI channel 12.
-Continued-
