Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Detailed Setup—Transducer Block
July 2013
105
Table 4‐14. Transducer Block Parameter Definitions (Continued)
Description
Protect
Category
Initial ValueRangeMode
RO /
RW
Index
Number
Label
PARAMETER_NAME
Travel Open Alert Point
TVL_OPEN_ALRT_PT
77.8 RW ALL -25% to 125% 99.5% SETUP
Data Type: Float
Alert when valve is open. Control DI
channel 24 regardless of alert enable
state.
Travel Open Deadband
TVL_OPEN_DB
77.9 RW ALL > = 0%, < =100% 1% SETUP
Data Type: Float
Deadband
Travel Closed Alert Point
TVL_CLOSED_ALRT_PT
77.10 RW ALL -25% to 125% 0.5% SETUP
Data Type: Float
Alerts when valve closed. Controls DI
channel 25 regardless of alert enable
state.
Travel Closed Deadband
TVL_CLOSED_DB
77.11 RW ALL > = 0%, < = 100% 1% SETUP
Data Type: Float
Deadband
Travel Lo Lo Alert Point
TVL_LO_LO_ALRT_PT
77.12 RW ALL -25% to 125% -25% SETUP
Data Type: Float
Alert when valve position is less than
alert point. Controls DI channels 26
& 30 regardless of alert enable state.
Travel Lo Lo Deadband
TVL_LO_LO_DB
77.13 RW ALL > = 0%, < = 100% 5% SETUP
Data Type: Float
Deadband
Travel Lo Alert Point
TVL_LO_ALRT_PT
77.14 RW ALL -25% to 125% -25% SETUP
Data Type: Float
Alert when valve position is less than
alert point. Controls DI channels 27
& 31 regardless of alert enable state.
Travel Lo Deadband
TVL_LO_DB
77.15 RW ALL > = 0%, < = 100% 5% SETUP
Data Type: Float
Deadband
Travel Hi Alert Point
TVL_HI_ALRT_PT
77.16 RW ALL -25% to 125% 125% SETUP
Data Type: Float
Alert when valve position is less than
alert point. Controls DI channels 28
& 32 regardless of alert enable state.
Travel Hi Deadband
TVL_HI_DB
77.17 RW ALL > = 0%, < = 100% 5% SETUP
Data Type: Float
Deadband
Travel Hi Hi Alert Point
TVL_HI_HI_ALRT_PT
77.18 RW ALL -25% to 125% 125% SETUP
Data Type: Float
Alert when valve position is less than
alert point. Controls DI channels 29
& 33 regardless of alert enable state.
Travel Hi Hi Deadband
TVL_HI_HI_DB
77.19 RW ALL > = 0%, < = 100% 5% SETUP
Data Type: Float
Deadband
-Continued-
