Instruction Manual
D103412X012
Detailed Setup—Transducer Block
July 2013
104
Table 4‐14. Transducer Block Parameter Definitions (Continued)
Description
Protect
Category
Initial ValueRangeMode
RO /
RW
Index
Number
Label
PARAMETER_NAME
INST_ALERTS_CONFIG
76
Shutdown Trigger
SHUTDOWN_TRIGGER
76.1 RW ALL
0: Drive Current
1: Program Memory
2: Static Memory
3: Processor or I/O
Processor
4: Travel Sensor
5: Port A Pressure Sensor
6: Output Block Timeout
7-31: (Reserved)
All bits: 0 SETUP
Data Type: Bit String (4 byte)
0=attempt control,
1=fail to zero drive e.g. OOS mode
Action on specific instrument alerts:
Shutdown Recovery
SHUTDOWN_RECOVERY
76.2 RW ALL
0: (reserved)
1: Program Memory
2: Static Memory
3: Processor or I/O
Processor
4: Travel Sensor
5: Port A Pressure Sensor
6: Output Block Timeout
7-31: (Reserved)
All bits: 0 SETUP
Data Type: Bit String (4 byte)
0=Auto
1=Manual
Recovery action after a shutdown
trigger “fail to zero drive” above,
Output Blk Timeout
OUTPUT_BLK_TIMEOUT
76.3 RW ALL
Time > = 0, < = 800
seconds
600 sec SETUP
Data Type: Float
The maximum time between
updates from the AO or DO block to
the transducer block setpoint.
Drive Current Alert Point
DRIVE_CURRENT_ALRT_PT
76.4 RW ALL > = 5, < = 100 25% SETUP
Data Type: Float
(percent different) drive signal not
reaching I/P accurately.
Drive Current Alert Time
DRIVE_CURRENT_TIME
76.5 RW ALL = 0.25, < = 120 seconds 5 sec SETUP
Data Type: Float
(percent different) drive signal not
reaching I/P accurately.
Temperature Hi Alert Point
TEMP_HI_ALRT_PT
76.6 RW ALL > -76 F, < 257 F 186 deg F SETUP
Data Type: Float
Temperature HI Limits
Temperature Lo Alert Point
TEMP_LO_ALRT_PT
76.7 RW ALL > -76 F, < 257 F -63 deg F SETUP
Data Type: Float
Temperature LO Limits
Supply Pressure Hi Alert Point
SUP_PRES_HI_ALRT_PT
76.8 RW ALL > = 0, < = 150 145 psig SETUP
Data Type: Float
Maximum supply pressure
Supply Pressure Lo Alert Point
SUP_PRES_LO_ALRT_PT
76.9 RW ALL > = 0, < = 150 15 psig SETUP
Data Type: Float
Minimum supply pressure
INST_ALERTS_CONFIG2
77
Travel Deviation Alert Point
TVL_DEV_ALRT_PT
77.1 RW ALL > 0%, <= 125% 5% SETUP
Data Type: Float
Alerts when difference between sp
and pv is too large for too long.
Travel Deviation Time
TVL_DEV_TIME
77.2 RW ALL > = 0, < = 120 seconds 10 sec SETUP Data Type: Float
Travel Deviation Deadband
TVL_DEV_DB
77.3 RW ALL > = 0%, < = 100% 2% SETUP Data Type: Float
Travel Accumulator Alert Point
TVL_ACCUM_ALRT_PT
77.4 RW ALL > = 0 1,000,000 SETUP
Data Type: Uint32
Alerts when accumulated travel is
too much
Travel Accumulator Deadband
TVL_ACCUM_DB
77.5 RW ALL 0 - 100% 1% SETUP
Data Type: Float
Deadband
Cycle Count Alert Point
CYCLE_COUNT_ALRT_PT
77.6 RW ALL > = 0 1,000,000 SETUP
Alerts when number of cycles is too
large.
Cycle Count Deadband
CYCLE_COUNT_DB
77.7 RW ALL 0 - 100% 1% SETUP
Data Type: Float
Deadband
-Continued-
