Detailed Setup—Transducer Block
July 2013
103
Table 4‐14. Transducer Block Parameter Definitions (Continued)
Description
Protect
Category
Initial ValueRangeMode
RO /
RW
Index
Number
Label
PARAMETER_NAME
INST_ALERTS_ENABLE
75
Electronics Enable
ELECT_ENABLE
75.1 RW ALL
0: Drive Current
1: Drive Signal
2: Program Memory
3: Static Memory
4: Processor
5: I/O Processor
6: Output Block Timeout
7: Blocks Set to Defaults
Enabled Bits:
0: Drive Current
1: Drive Signal
2: Program
Memory
3: Static Memory
4: Processor
5: I/O Processor
7: Block Set to
Default
SETUP
Data Type: Bit String (4 byte)
0=disable
1=enable
Electronic Alerts Enable
Sensor Enable
SENSOR_ENABLE
75.2 RW ALL
0: Travel Sensor
1: Port A Pressure Sensor
2: Port B Pressure Sensor
3: Supply Pressure
Sensor
4: Temperature Sensor
Enabled Bits:
0: Travel Sensor
1: Port A Pressure
Sensor
2: Port B Pressure
Sensor
3: Supply Pressure
Sensor
4: Temperature
Sensor
SETUP
Data Type: Bit String (4 byte)
0=disable
1=enable
Sensor Alerts Enable
Environment Enable
ENVIRO_ENABLE
75.3 RW ALL
0: Supply Pressure High
1: Supply Pressure Low
2: Temperature High
3: Temperature Low
Enabled Bits:
0: Supply Pressure
High
2: Temperature
High
3: Temperature
Low
SETUP
Data Type: Bit String (4 byte)
0=disable
1=enable
Environment Alerts Enable
Travel Enable
TRAVEL_ENABLE
75.4 RW ALL
0: Travel Deviation
1: Travel High High
2: Travel Low Low
3: Travel High
4: Travel Low
Enabled Bits:
0: Travel
Deviation
SETUP
Data Type: Bit String (4 byte)
0=disable
1=enable
Travel Alerts Enable
Proximity Enable
PROX_ENABLE
75.5 RW ALL
0: Travel Open
1: Travel Closed
2: Proximity High High
3: Proximity High
4: Proximity Low
5: Proximity Low Low
All bits: 0 SETUP
Data Type: Bit String (4 byte)
0=disable
1=enable
Proximity Alerts Enable
Travel History Enable
TVL_HISTORY_ENABLE
75.6 RW ALL
0: Cycle Counter
1: Travel Accumulator
All bits: 0 SETUP
Data Type: Bit String (4 byte)
0=disable
1=enable
Travel History Alerts Enable
Performance Enable
PERF_ENABLE
75.7 RW ALL
0: Performance Critical
1: Performance Reduced
2: Performance
Information
Enabled Bits:
0: Performance
Critical
1: Performance
Reduced
SETUP
Data Type: Bit String (4 byte)
0=disable
1=enable
Performance Alerts Enable
-Continued-
