Instruction Manual
D103412X012
Viewing Device Variables and Diagnostics
July 2013
228
Device Record
Field Communicator TB > Device Diagnostic > Device Record
The following parameters are contained in the Device Record menu of the transducer block.
Maximum Recorded Temperature—Maximum Recorded Temperature (TEMP_MAX [86.1]) shows the maximum
temperature the instrument has experienced since installation.
Maximum Recorded Temperature Time—Maximum Recorded Temperature Time (TEMP_MAX_TIME [86.2]) shows
the date and time when the Temperature Maximum occurred.
Minimum Recorded Temperature—Minimum Recorded Temperature (TEMP_MIN [86.3]) shows the minimum
temperature the instrument has experienced since installation.
Minimum Recorded Temperature Time—Minimum Recorded Temperature Time (TEMP_MIN_TIME [86.4]) shows
the date and time when the Temperature Minimum occurred.
Maximum Recorded Supply Pressure—Maximum Recorded Supply Pressure (SUPPLY_PRESS_MAX [86.5]) shows the
maximum supply pressure the instrument has experienced since installation.
Maximum Recorded Supply Pressure Time—Maximum Recorded Supply Pressure Time (SUPP_PRESS_MAX_TIME
[86.6]) shows the date and time when the Supply Pressure Maximum occurred.
Minimum Recorded Supply Pressure—Minimum Recorded Supply Pressure (SUPP_PRESS_MIN [86.7]) shows the
minimum supply pressure the instrument has experienced since installation.
Minimum Recorded Supply Pressure Time—Minimum Recorded Supply Pressure Time (SUPP_PRESS_MIN_TIME
[86.8]) shows the date and time when the Supply Pressure Minimum occurred.
Stroking the Digital Valve Controller Output
Field Communicator TB > Device Diagnostic > Stroke Valve
Stroke Valve is used to confirm proper valve operation. Follow the prompts on the Field Communicator display to
select from the following: Done, Ramp Open, Ramp Closed, Ramp to Target, Step to Target, and Stop.
Done—Select this if you are done. All ramping is stopped when DONE is selected.
Ramp Open—ramps the travel toward open at the rate of 1.0% per second of the ranged travel.
Ramp Closed—ramps the travel toward closed at the rate of 1.0% per second of the ranged travel.
Ramp to Target—ramps the travel to the specified target at the rate of 1.0% per second of the ranged travel.
Step to Target—steps the travel to the specified target.
Stop—stops the command.
