Fisher FIELDVUE DVC6200f User Manual

Instruction Manual
D103412X012
Operating with a DeltaV System
July 2013
306
Table F‐1. Transducer Block (TB) Parameters - Configuration Index (Continued)
Path to ParameterParameter Label
Pressure A TB > Device Variables > Overview > Pressures: Pressure A
Pressure A Sensor Failure TB > Device Diagnostics > Status > Self Test Status: Pressure A Sensor Failure
Pressure B TB > Device Variables > Overview > Pressures: Pressure B
Pressure B Sensor Failure TB > Device Diagnostics > Status > Self Test Status: Pressure B Sensor Failure
Pressure Differential TB > Device Variables > Overview > Pressures: Pressure Diff
Pressure Fallback Alert TB > Configure/Setup > Detailed Setup > Alerts > Sensor > Pressure Fallback: Pressure Fallback Alert
Pressure Fallback Alert Enable TB > Configure/Setup > Detailed Setup > Alerts > Sensor > Pressure Fallback: Pressure Fallback Alert Enable
Pressure Units TB > Configure/Setup > Detailed Setup > Instrument > Units: Pressure Units
Processor Alert TB > Configure/Setup > Detailed Setup > Alerts > Electronic > Processor Impaired: Processor Alert
Processor Alert Enable TB > Configure/Setup > Detailed Setup > Alerts > Electronic > Processor Impaired: Processor Alert Enable
Program Memory Alert Enable TB > Configure/Setup > Detailed Setup > Alerts > Electronic > Processor Impaired: Program Memory Alert Enable
Program Memory Manual Recovery TB > Configure/Setup > Detailed Setup > Alerts > Electronic > Processor Impaired: Program Memory Manual Recovery
Program Memory Shutdown TB > Configure/Setup > Detailed Setup > Alerts > Electronic > Processor Impaired: Program Memory Shutdown
Program Memory Alert TB > Configure/Setup > Detailed Setup > Alerts > Electronic > Processor Impaired: Program Memory Alert
Protection TB > Device Variables > Overview > Protection
Proximity Hi Alert TB > Configure/Setup > Detailed Setup > Alerts > Proximity > Proximity: Proximity Hi Alert
Proximity Hi Alert Enable TB > Configure/Setup > Detailed Setup > Alerts > Proximity > Proximity: Proximity Hi Alert Enable
Proximity Hi Hi Alert TB > Configure/Setup > Detailed Setup > Alerts > Proximity > Proximity: Proximity Hi Hi Alert
Proximity Hi Hi Alert Enable TB > Configure/Setup > Detailed Setup > Alerts > Proximity > Proximity: Proximity Hi Hi Alert Enable
Proximity Lo Alert TB > Configure/Setup > Detailed Setup > Alerts > Proximity > Proximity: Proximity Lo Alert
Proximity Lo Alert Enable TB > Configure/Setup > Detailed Setup > Alerts > Proximity > Proximity: Proximity Lo Alert Enable
Proximity Lo Lo Alert TB > Configure/Setup > Detailed Setup > Alerts > Proximity > Proximity: Proximity Lo Lo Alert
Proximity Lo Lo Alert Enable TB > Configure/Setup > Detailed Setup > Alerts > Proximity > Proximity: Proximity Lo Lo Alert Enable
Push Down To TB > Configure/Setup > Detailed Setup > Valve and Actuator > Trim > Push Down To
Simulate PlantWeb Alerts TB > Configure/Setup > Detailed Setup > Alert Handling > Simulate PlantWeb Alerts
Rated Travel TB > Configure/Setup > Detailed Setup > Valve and Actuator > Valve > Rated Travel
Relay Type TB > Configure/Setup > Detailed Setup > Instrument > Application: Relay Type
Seat Type TB > Configure/Setup > Detailed Setup > Valve and Actuator > Trim > Seat Type
Setpoint TB > Device Variables > Overview > AO Control‐Pre‐Characterization: Setpoint
Setpoint Status TB > Device Variables > Overview > AO Control‐Pre‐Characterization: Setpoint Status
Setpoint(D) TB > Device Variables > Overview > DO Control: Setpoint(D)
Shaft Stem Diameter TB > Configure/Setup > Detailed Setup > Valve and Actuator > Valve > Shaft Stem Dia
Simulate Active TB > Device Diagnostics > Status > Transducer Block Error: Simulate Active
Simulate Jumper ON TB > Device Diagnostics > Status > Self Test Status: Simulate Jumper ON
Spring Rate TB > Configure/Setup > Detailed Setup > Valve and Actuator > Actuator > Spring Rate
Spring Rate Units TB > Configure/Setup > Detailed Setup > Instrument > Units: Spring Rate Units
Static Memory Alert TB > Configure/Setup > Detailed Setup > Alerts > Electronic > Processor Impaired: Static Memory Alert
Static Memory Alert Enable TB > Configure/Setup > Detailed Setup > Alerts > Electronic > Processor Impaired: Static Memory Alert Enable
Static Memory Manual Recovery TB > Configure/Setup > Detailed Setup > Alerts > Electronic > Processor Impaired: Static Memory Manual Recovery
Static Memory Shutdown TB > Configure/Setup > Detailed Setup > Alerts > Electronic > Processor Impaired: Static Memory Shutdown
Stroke Time Close TB > Configure/Setup > Detailed Setup > Valve and Actuator > Reference > Stroke Time Close
Stroke Time Open TB > Configure/Setup > Detailed Setup > Valve and Actuator > Reference > Stroke Time Open
Supply Pressure Maximum TB > Device Diagnostics > Device Record > Supp Pressure Max
Supply Pressure Maximum Time TB > Device Diagnostics > Device Record > Supp Pressure Maximum Time
Supp Pressure Minimum TB > Device Diagnostics > Device Record > Supp Pressure Minimum
Supp Pressure Minimum Time TB > Device Diagnostics > Device Record > Supp Pressure Minimum Time
Supply Pressure TB > Configure/Setup > Detailed Setup > Alerts > Environment > Supply Pressure: Supply Pressure
Supply Pressure TB > Device Variables > Overview > Pressures: Supply Pressure
Supply Pressure Hi Alert TB > Configure/Setup > Detailed Setup > Alerts > Environment > Supply Pressure: Supply Pressure Hi Alert
Supply Pressure Hi Alert Enable TB > Configure/Setup > Detailed Setup > Alerts > Environment > Supply Pressure: Pressure Hi Alert Enable
Supply Pressure Hi Alert Point TB > Configure/Setup > Detailed Setup > Alerts > Environment > Supply Pressure: Supply Pressure Hi Alert Point
Supply Pressure Lo Alert TB > Configure/Setup > Detailed Setup > Alerts > Environment > Supply Pressure: Supply Pressure Lo Alert
Supply Pressure Lo Alert Enable TB > Configure/Setup > Detailed Setup > Alerts > Environment > Supply Pressure: Supply Pressure Lo Alert Enable
Supply Pressure Lo Alert Point TB > Configure/Setup > Detailed Setup > Alerts > Environment > Supply Pressure: Supply Pressure Lo Alert Point
-Continued-
